Features:

Drag-and-drop DXF import or via Tools menu
LINE, ARC, CIRCLE, LWPOLYLINE, POLYLINE, SPLINE (NURBS), POINT entities
Three modes: Actors Only, Assets Only, or Both
Layer filtering with checkbox UI
DXF color retention — ACI, 24-bit RGB, BYLAYER
Auto unit scaling
Outliner hierarchy grouped by DXF layer (and sublayer if available, eg. from Rhino)
Export splines back to DXF
Spline Tools: Explode, Join, Center Pivot
Randomization Tools: sub-select %, random scale/rotation/offset

Code Modules:

DXFSplineImporter (Editor)

Number of Blueprints: 0
Number of C++ Classes: 8 (FDXFParser, FDXFSplineSpawner, FDXFExporter, UDXFFactory, SDXFImportDialog, SArchvizSplineToolsDialog, SArchvizRandomToolsDialog, FDXFSplineImporterModule)
Network Replicated: No

Supported Development Platforms:

Windows: Yes
Mac: No

Supported Target Build Platforms: N/A (Editor only plugin — does not ship in packaged builds)
Documentation Link: https://github.com/pbrgle1/CADbridge-docs

Important/Additional Notes: This is an editor-only tool designed for architectural visualization workflows. It does not include any runtime components. Blueprint compilation can be slow for large DXF files — use "Actors Only" mode for faster imports when reusable Blueprint assets are not needed.
