Code Modules:

VoxelGI — Runtime (LoadingPhase: PostConfigInit, Win64)
VoxelGIEditor — Editor (LoadingPhase: Default, Win64)

Number of Blueprints:

0 (pure C++ plugin, ships no content)

Number of C++ Classes:

15 (2 module classes, 1 scene view extension, 1 UObject settings class, 1 view-parameters struct, 10 global-shader classes)

Network Replicated:

No (rendering-only, no replicated state)

Supported Development Platforms:

Windows: Yes, Mac: No

Supported Target Build Platforms:

Win64 only. Requires the D3D12 RHI with hardware ray tracing (DXR); the plugin uses inline ray tracing (RayQuery) for voxelization and optional material reflection rays. No Mac/Metal, Linux, or console support.

Documentation Link:

https://unrealvoxel.pterosoftstudio.com/documentation/

Example Project:

www.pterosoftstudio.com/VoxelGISponza.zip

Important/Additional Notes:

- Requires a GPU supporting hardware ray tracing (DXR / inline ray tracing, SM6) on D3D12. Voxelization force-builds the ray tracing scene (TLAS).

- Real-time voxel-cone-traced diffuse GI + AO, optional rough specular cone and material ray-traced reflections; composites into scene color before DOF via an FSceneViewExtension. Independent of Lumen (disable Lumen when validating).

- Settings are in a top-level "Voxel GI" editor main-menu entry.

- Packaged for UE 5.7; source also compiles on 5.8
