Hydraulic Power Unit

High-quality 3d model optimized for product visualization, simulations, and real-time rendering.

1. Technical Specifications

- The provided textures are created in full compliance with the PBR Metallic workflow.

- Texture Maps: BaseColor, Roughness, Metallic, Normal, AO, Opacity, Emission, Transmission

- Texture Resolutions: 4096x4096px, 8-bit PNG

- Normal Map Format: OpenGL (+X, +Y, +Z). Note: Invert the Green channel (Y) if your engine requires DirectX.

- UV: Non-overlapping

- Texel Density: 13 px/cm

- Mesh Structure: 4 mesh object(s)

- Geometry:

- Faces: 136084

- Vertices: 140370

- Triangles: 271508

- Dimensions: x:149cm, y:244cm, z:201cm

- Scene Setup: The model pivot is set to world origin (0, 0, 0) for immediate, hassle-free placement in any scene. All transforms (location, rotation, and scale) are fully applied. Every mesh object, material, and texture is clearly named following a logical, descriptive convention for easy navigation and re-use.

2. Formats and Engine Support

Blender 5.1.0

- Materials are fully configured for PBR Metallic workflow and Cycles.

- Textures packed into the .blend scene file.

Unreal Engine 5.7.4

- Built natively with the Substrate shading system (must be enabled in Project Settings for correct rendering).

- Fully compatible with Lumen and Ray Tracing (ensure these features are enabled in Project Settings).

- AO, Roughness, and Metallic maps are packed into a single ORM texture (R=AO, G=Roughness, B=Metallic) for convenience and optimization.

- Included as a grouped Blueprint actor for easy scene placement.

- The scene is lit with a high-quality HDRI from Poly Haven (CC0 License). The "HDRI Backdrop" plugin must be enabled in project settings.

Universal Formats (FBX / OBJ)

- Universal FBX and OBJ formats include geometry data but do not have pre-configured materials. Using the provided textures, you can recreate the 3D object in any modern 3D software following the PBR Metallic workflow.
